Program the temperature controller – MTS Model FlexTest SE User Manual
Page 166
Models FlexTest® IIm/GT/SE Controller Hardware
Eurotherm Temperature Controller Connection
FlexTest GT Controller Connections
166
Program the
temperature controller
Use the Station Builder application to configure a Eurotherm temperature
controller.
.
J50D
J7 SERIAL
J50C
J50B
J50A
m
493.71
Serial
Interface
CLOCK OUT
EVENT OUT
J3 IN
J6 STATION
J7 SERIAL
EVENT IN
J4 OUT
J5 DEBUG
+12V
m
498.71B
GRES III
056-172-0xx (for Model 652/653 Temperature Chambers)
056-128-0xx (for Model 651 Temperature Chambers)
049-876-501
Eurotherm
Temperature
Controller
Use Jumper Plug 055-634-101
in these connectors.
