Models FlexTest® IIm/GT/SE Controller Hardware Model 493.07 Converter Box 252
Note If the Model 493.10 Chassis is the only device connected to the HPU, the
jumper settings do not matter.
Note The Model 493.07 Converter Box cannot be used with both groups of
controllers at the same time. If this functionality is needed, use an HPU
isolation box.
C OMPATIBLE WITH J UMPERS
Model 458.05/.10/.20/.40
Model 490.01
Model 497.05 Standard jumper setting:
E10–E11install
E12–E13 install
E14–E15 install
E16–E17 install
E10–E13 remove
E14–E17 remove
Model 413.05
Model 436.11
Model 407.05 Jumper change required:
E10–E11 remove
E12–E13 remove
E14–E15 remove
E16–E17 remove
E10–E13 install
E14–E17 install
