How to Program an External Controller
Models FlexTest® IIm/GT/SE Controller Hardware FlexTest IIm Controller Connections 207
Sample conditioner
output connections
This table shows connector assignments for various MTS products you can use
with your FlexTest IIm controller.
Task 1 Create your configuration file with Station Builder.
Using Station Builder, define controller resources to provide programming to an
external controller.
For more information, see “How to Create Your Station Configuration File” and
“Creating Program Channels” in the MTS 793 Control Software manual.
Task 2 Adjust the signals with Station Manager.
Adjust program signal Adjust the outgoing program signal for the required external controller channel.
For more information, see “How to Adjust Program Output Signals” in the MTS
793 Control Software manual.
Adjust feedback
signals
If you will monitor sensor feedback for data acquisition or control feedback,
adjust the incoming feedback signals.
Conditioning Sensors with Other MTS Products
MTS P RODUCT S ENSOR O UTPUT
Model 408.81 Testing Panel/
Model 408.82 DC Conditioner Sensor output is available at the rear-panel connector J201
or J202.
Model 409.81C Temperature Controller Temperature output (via an analog signal) is available at
rear-panel connector J1.
Model 448.82/85 Test Controller with
Model 448.21/22 AC and DC Conditioners Sensor output is available at rear-panel connector J335.
Ensure sensor conditioners are set as follows:
X1: 2&3
X2: 2&3
Model 458.10/20 MicroConsole ® with
Model 458.11/12/13/14 AC and DC
Controllers
Sensor output is available at the MicroConsole rear-panel
connector Jx03. Connector Jx03 represents the module
location (J100–J600).
MicroConsole jumper Jx00 should be set to 1&2 (standard
setting).
