Spare parts for system cables
Plug−in connector properties
Cable end on the controller side
l
857
EDSYPFLD EN 8.0
14.6.2
Cable end on the controller side
Characteristic
No.
of
pole
s
Rated voltage
Core
cross−section
Spare
contact
Number of
contacts required
Plug−in
connector
Power
EWS1016
6
AC/DC 630 V
1.0 ... 2.5 mm
2
EWZ0059
6
P04
EWS1014
8
AC/DC 630 V
0.5 ... 1.0 mm
2
EWZ0060
2
P05
2.5 ... 4.0 mm
2
EWZ0061
4
EWS1015
8
AC/DC 630 V
0.5 ... 1.0 mm
2
EWZ0060
2
P06
6.0 ... 16.0 mm
2
EWZ0062
4
EWS1080
8
AC/DC 630 V
0.5 ... 1.0 mm
2
EWZ0057
4
P07
0.5 ... 2.5 mm
2
EWZ0059
4
EWS0081
9
AC 500 V
1.5 mm
2
–
–
Q08
2.5 mm
2
Q09
EWS0083
8
AC 500 V
1.5 mm
2
–
–
Q10
2.5 mm
2
Q11
Blower
EWS1002
8
AC/DC 630 V
1.0 ... 2.5 mm
2
EWZ0057
4
J03
1.0 ... 2.5 mm
2
EWZ0059
1
EWS1022
7
AC/DC 630 V
1.0 ... 1.5 mm
2
EWZ0058
7
J04, J05
Feedback
EWS1007
12
AC/DC 125 V
0.14 ... 1.0 mm
2
EWZ0058
9
G06
EWS1011
12
AC/DC 125 V
0.14 ... 1.0 mm
2
EWZ0058
10
G07
EWS1018
17
AC/DC 125 V
0.14 ... 0.5 mm
2
EWZ0058
14
G08
EWS1024
17
AC/DC 125 V
0.14 ... 0.5 mm
2
EWZ0058
16
G09
EWZ0040
9
AC/DC 50 V
0.14 mm
2
–
–
S01
EWZ0047
9
AC/DC 50 V
0.14 mm
2
–
–
S02
EWZ0048
15
AC/DC 50 V
0.14 ... 0.5 mm
2
–
–
S03
EWZ0051
9
AC/DC 50 V
0.14 mm
2
–
–
S04
EWZ0052
9
AC/DC 50 V
0.14 mm
2
–
–
S05
EWZ0063
15
AC/DC 50 V
0.14 ... 0.5 mm
2
–
–
S06
EWZ0049
9
AC/DC 50 V
0.14 mm
2
–
–
W02
EWZ0070
1)
9
AC/DC 50 V
0.14 mm
2
–
–
W04
1)
When Sub−D plug EWZ0070 is used, an additional free space of 50 mm must be considered due to the depth of the
plug. If the required free space is not available, a connection cable for fixed installation and plug EWZ0049 can be
used in combination with an extension cable suitable for trailing to solve the application.
)
Note!
The number of poles refers to the visible poles and not to the number of
physically present contacts or number of cores suitable for connection.
