Three−phase asynchronous motors MHxMA: Motor cable selection
MHxMAxx112−22
Delta connection − terminal box, 8−core system cable
7
l
663 EDSYPFLD EN 8.0
7.3.11 Delta connection − terminal box, 8−core system cable
U
V
W
[mm 2 ] E94Ax EVF93 E82xV E84AV E84DVB
E84DS
E84DH
MHxMAxx112−22, - (4 Ч 2.5 + 2(2 Ч 0.5)) U, V, W, PE, , J
X1,
X21
X21
Connection cable
U
V
W
Connection cable
(4 Ч 2.5 + 2(2 Ч 0.5))
EYP0038AxxxxA00A00
E94Ax
EVF93
E82xV
E84AV
E84DVB (X1)
EYP0038AxxxxA00Q11
E84DVB (X21)
E84DSxC
E84DHxC
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
