Blower cable selection
MxFMA motor
1−phase fan with plug connection
10
l
802 EDSYPFLD EN 8.0
10.4 MxFMA motor
10.4.1 1−phase fan with plug connection
U
V
W
[mm 2 ]
MDFMA... 5 × 1.0
Connection cable
U
V
W
Connection cable
5 × 1.0
EYL0001AxxxxL02A00
EYL0002AxxxxL02A00
EYL0001AxxxxL04A00
EYL0002AxxxxL04A00
Extension cable
U
V
W
Extension cable Connection cable
5 × 1.0
EYL0001VxxxxL02J04 EYL0001AxxxxL02A00
EYL0001VxxxxL04J04 EYL0002AxxxxL02A00
EYL0002VxxxxL02J04 EYL0001AxxxxL04A00
EYL0002VxxxxL04J04 EYL0002AxxxxL04A00
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27
