Feedback cable selection
Encoder cables
IG512−24V−H, IGxxxx−24V−H (HTL with 10−core system cable)
11
l
817 EDSYPFLD EN 8.0
Feedbacks with terminal boxes
[mm 2 ] EVF93 E84AVH E84AVT E82xV
IG512−24V−H
IG1024−24V−H
IG2048−24V−H
4 (2 Ч 0.14) + (2 Ч 1.0) X8 X5 X5 X3 1)
1) Connection via the E82ZAFSC module or the E82ZAFAC module is possible.
Connection cable
Connection cable
EYF0018AxxxxA00W02
EVF93
EYF0019AxxxxA00W04
EYF0018YxxxxA00A00 E82xV
E84AVH
E84AVT
EYF0019YxxxxA00A00
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27
