How to select your system cable
Digital frequency cables
How to find your digital frequency cable
4
l
74 EDSYPFLD EN 8.0
4.4 Digital frequency cables
For your convenience, choose your customised digital frequency cable using a maximum
of two tables. The structure of the tables always provides for the same order in which the
components appear (’controller (master) − digital frequency cable − controller (slave)’).
4.4.1 How to find your digital frequency cable
1. Use the bookmarklets of the PDF document to select your controller (master) in the
chapter "Selection of digital frequency cables".
2. Navigate to the corresponding chapter.
3. In the "Controller type" selection table, the controllers (slaves) are listed, to which
the controller (master) can be connected.
– Structure of the "Controller type" selection table: (
¶ 75)
4. Select a connecting cable.
– Structure of the "Connection cable" selection table: (
¶ 76)
5. Determine the product key of the connection cable.
– The product key gives information about the cross−section, the laying system, and
the design of the cable ends.
– The product key also is the order designation.
