Three−phase asynchronous motors MFxxx: Motor cable selection
MFxMAxx090−32
Star connection − terminal box, 6−core system cable
8
l
765 EDSYPFLD EN 8.0
8.3.4 Star connection − terminal box, 6−core system cable
U
V
W
[mm 2 ] E94Ax EVF93 E82xV E84AV
MFxxxx090−32
(4 Ч 1.0 + (2 Ч 0.5)) U, V, W, PE, J
(4 Ч 1.5 + (2 Ч 0.5))
[U, V, W, PE, ]
(4 Ч 2.5 + (2 Ч 0.5))
Connection cable
U
V
W
Connection cable
(4 Ч 1.0 + (2 Ч 0.5))
EYP0003YxxxxA00A00 E94Ax
EVF93
E82xV
E84AV
EYP0010YxxxxA00A00
(4 Ч 1.5 + (2 Ч 0.5))
EYP0004YxxxxA00A00 E94Ax
EVF93
E82xV
E84AV
EYP0011YxxxxA00A00
(4 Ч 2.5 + (2 Ч 0.5))
EYP0005YxxxxA00A00 E94Ax
EVF93
E82xV
E84AV
EYP0012YxxxxA00A00
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
