Three−phase asynchronous motors MDxMA: Motor cable selection
MDxMAxx112−32
Delta connection − terminal box, 10−core system cable
6
l
562 EDSYPFLD EN 8.0
6.8.8 Delta connection − terminal box, 10−core system cable
U
V
W
[mm 2 ] E94Ax EVF93 E82xV E84AV
E84DS
E84DH
MDxMAxx112−32, - (4 Ч 4.0 + (2 Ч 1.0) + (4 Ч 1.0)) U, V, W, PE, ,
J ˘
Connection cable
U
V
W
Connection cable
(4 Ч 4.0 + (2 Ч 1.0) + (4 Ч 1.0))
EYP0046AxxxxA00A00
E94Ax
EVF93
E82xV
E84AV
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
