Technical data
Enclosure
Cable end of digital frequency cable
3
l
58 EDSYPFLD EN 8.0
3.2.3 Cable end of digital frequency cable
This characteristic describes the cable ends of the digital frequency cables.
Characterist
ic No. of
poles Maximum voltage Core
cross−section Type
Digital frequency
W01 9 AC/DC 50 V 0.14 mm 2 Sub−D plug (socket)
W03 9 AC/DC 50 V 0.14 mm 2 Sub−D plug (socket), with locking tab
S01 9 AC/DC 50 V 0.14 mm 2 Sub−D plug (pin)
S02 9 AC/DC 50 V 0.14 mm 2 Sub−D plug (pin), with locking tab
S07, S08,
S09, S10 15 AC/DC 50 V 0.14 mm 2 Sub−D plug (pin), with locking tab
3.3 Enclosure
The prepared system cables comply with the IP65 enclosure.
Exception:
ƒ System cables with a Sub−D connector
ƒ System cables with an open cable end
