4 How to select your system cable
4.1 Motor cables
For your convenience, choose your customised motor cable using a maximum of three
tables. The structure of the tables always provides for the same order in which the
components appear (’motor − motor cable − controller’).
)
Note!
For controllers, only the device series are listed and not the single device types.
The connectable cable cross−sections can be obtained from the documentation
of the controllers.
4.1.1 How to find your motor cable
1. Observe the chapter "Dimensioning of the motor cables". ( ¶ 24)
2. Use the bookmarklets in the PDF document to select your servo motor or
three−phase asynchronous motor.
3. Navigate to the corresponding chapter.
4. In the "Motor type" selection table, the controllers with which the motor can be
used are listed.
– Structure of the "Motor type" selection table: (
¶ 60)
5. Select a connection cable or a combination of connection cable and extension cable.
– Structure of the "Connection cable" selection table: (
¶ 61)
– Structure of the "Extension cable" selection table: (
¶ 62)
6. Determine the product key of the connection cable or the extension cable,
respectively.
– The product key gives information about the cross−section, the laying system, and
the design of the cable ends.
– The product key also is the order designation.
