Servo motors: Motor cable selection
MQA motor
MQA20L29
5
l
408 EDSYPFLD EN 8.0
Motors with terminal boxes
U
V
W
[mm 2 ]
EVS93
E84AVT
E94AS
E94AM
ECS
MQA20L29− 2Fxx
(4 Ч 10.0 + (2 Ч 1.0))
U, V, W, PE X105, X107 X24, X25
(4 Ч 16.0 + (2 Ч 1.0))
Connection cable
U
V
W
Connection cable
(4 Ч 10.0 + (2 Ч 1.0))
–
E94AS
E94AM
EVS93
ECS
E84AVT
EYP0015YxxxxA00A00
(4 Ч 16.0 + (2 Ч 1.0))
EYP0009YxxxxA00A00
E94AS
E94AM
EVS93
ECS
E84AVT
EYP0016YxxxxA00A00
The EYP0009... system cable can only be connected to the motor using an enlarger.
The EYP0016... system cable can only be connected to the motor using an enlarger.
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
