Blower cable selection
MDFKS motor
1−phase fan with plug connection
10
l
800 EDSYPFLD EN 8.0
10.3 MDFKS motor
10.3.1 1−phase fan with plug connection
U
V
W
[mm 2 ]
MDFKS... 5 × 1.0
Connection cable
U
V
W
Connection cable
5 × 1.0
EYL0001AxxxxL01A00
EYL0002AxxxxL01A00
EYL0001AxxxxL03A00
EYL0002AxxxxL03A00
Extension cable
U
V
W
Extension cable Connection cable
5 × 1.0
EYL0001VxxxxL01J03 EYL0001AxxxxL01A00
EYL0001VxxxxL03J03 EYL0002AxxxxL01A00
EYL0002VxxxxL01J03 EYL0001AxxxxL03A00
EYL0002VxxxxL03J03 EYL0002AxxxxL03A00
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27
