Lenze EY System cables and system connectors - Manual (Page 33)

Product description
Overview of possible configurations
Eight−core motor cables
2
l
33 EDSYPFLD EN 8.0
2.3.2 Eight−core motor cables
Connection cable with connector, see (
¶ 34)
U
U
V
V
W
W
EYP xxxx A xxxx M0x A00
EYP xxxx A xxxx M0x Q1x
EYP xxxx A xxxx H1x A00
EYP xxxx A xxxx H1x Q1x
U
V
PE
W
EYP xxxx A xxxx A00 Q1x
hb_motor_05
Connection cable without connector, see (
¶ 35)
U
V
W
U
V
PE
W EYP xxxx Y xxxx A00 A00
hb_motor_03
Extension cable, see (
¶ 36)
EYP xxxx V xxxx H1x P07
EYP xxxx V xxxx M0x P07
EYP xxxx A xxxx M0x A00
EYP xxxx A xxxx M0x Q1x
EYP xxxx V xxxx A00 P07
U
V
PE
W
U
U
V
V
W
W
hb_motor_07
)
Note!
Always use a P07 circular connector to combine the eight−core extension
cables with the corresponding connection cables.
