Lenze EY System cables and system connectors - Manual (Page 416)

Servo motors: Motor cable selection
MQA motor
MQA26T05
5
l
416 EDSYPFLD EN 8.0
5.6.6 MQA26T05
Motors with terminal boxes
U
V
W
[mm 2 ]
EVS93
E84AVT
E94AS
E94AM
ECS
MQA26T05− 2Fxx
(4 Ч 10.0 + (2 Ч 1.0))
U, V, W, PE X105, X107 X24, X25
(4 Ч 16.0 + (2 Ч 1.0))
Connection cable
U
V
W
Connection cable
(4 Ч 10.0 + (2 Ч 1.0))
–
E94AS
E94AM
EVS93
ECS
E84AVT
EYP0015YxxxxA00A00
(4 Ч 16.0 + (2 Ч 1.0))
EYP0009YxxxxA00A00
E94AS
E94AM
EVS93
ECS
E84AVT
EYP0016YxxxxA00A00
Die EYP0009... system cable can only be connected to the motor using a reducer.
Die EYP0015... system cable can only be connected to the motor using a reducer.
Die EYP0016... system cable can only be connected to the motor using a reducer.
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
