Three−phase asynchronous motors 13.7x0: Motor cable selection
13.710.xx, 13.750.xx
Star or delta connection − terminal box, 6−core system cable
9
l
795 EDSYPFLD EN 8.0
9 Three−phase asynchronous motors 13.7x0: Motor cable selection
9.1 13.710.xx, 13.750.xx
9.1.1 Star or delta connection − terminal box, 6−core system cable
U
V
W
[mm 2 ] E94Ax EVF93 E82xV E84AV
13.710.35
13.710.47
13.710.55
13.750.45
13.750.55
13.750.65
(4 Ч 1.0 + (2 Ч 0.5)) U, V, W, PE, J
(4 Ч 1.5 + (2 Ч 0.5))
[U, V, W, PE, ]
(4 Ч 2.5 + (2 Ч 0.5))
Connection cable
U
V
W
Connection cable
(4 Ч 1.0 + (2 Ч 0.5))
EYP0003YxxxxA00A00 E94Ax
EVF93
E82xV
E84AV
EYP0010YxxxxA00A00
(4 Ч 1.5 + (2 Ч 0.5))
EYP0004YxxxxA00A00 E94Ax
EVF93
E82xV
E84AV
EYP0011YxxxxA00A00
(4 Ч 2.5 + (2 Ч 0.5))
EYP0005YxxxxA00A00 E94Ax
EVF93
E82xV
E84AV
EYP0012YxxxxA00A00
The EYP0004... system cable can only be connected to the motor using an extension.
The EYP0005... system cable can only be connected to the motor using an enlarger.
The EYP0010... system cable can only be connected to the motor using an extension.
The EYP0011... system cable can only be connected to the motor using an extension.
The EYP0012... system cable can only be connected to the motor using an enlarger.
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
