Blower cable selection
MDFKS motor
1−phase fan with terminal box
10
l
801 EDSYPFLD EN 8.0
10.3.2 1−phase fan with terminal box
U
V
W
[mm 2 ]
MDFKS... 5 × 1.0
Connection cable
U
V
W
Connection cable
5 × 1.0
EYL0001YxxxxA00A00
EYL0002YxxxxA00A00
Extension cable
U
V
W
Extension cable Connection cable
5 × 1.0
EYL0001VxxxxA00J03
EYL0001AxxxxL01A00
EYL0002AxxxxL01A00
EYL0002VxxxxA00J03
EYL0001AxxxxL03A00
EYL0002AxxxxL03A00
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27
