Three−phase asynchronous motors MHxMA: Motor cable selection
MHxMAxx132−22
Delta connection − terminal box, 10−core system cable
7
l
710 EDSYPFLD EN 8.0
7.5.8 Delta connection − terminal box, 10−core system cable
U
V
W
[mm 2 ] E94Ax EVF93 E82xV E84AV
E84DS
E84DH
MHxMAxx132−22, - (4 Ч 10.0 + (2 Ч 1.0) + (4 Ч 1.0)) U, V, W, PE, ,
J ˘
Connection cable
U
V
W
Connection cable
(4 Ч 10.0 + (2 Ч 1.0) + (4 Ч 1.0))
EYP0047AxxxxA00A00
E94Ax
EVF93
E82xV
E84AV
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
