Lenze EY System cables and system connectors - Manual (Page 171)

Servo motors: Motor cable selection
MCS motor
MCS06
5
l
171 EDSYPFLD EN 8.0
5.2 MCS motor
5.2.1 MCS06
Motors with plug connections
U
V
W
[mm 2 ]
EVS93
E84AVT
E94AS
E94AM
ECS
MCS06C41−...S00
MCS06C41L...S00
MCS06C60−...S00
MCS06C60L...S00
MCS06F41−...S00
MCS06F41L...S00
MCS06F60−...S00
MCS06F60L...S00
MCS06I41−...S00
MCS06I41L...S00
MCS06I60−...S00
MCS06I60L...S00
(4 Ч 1.0 + (2 Ч 0.5))
U, V, W, PE X105, X107 X24, X25 (4 Ч 1.5 + (2 Ч 0.5))
(4 Ч 2.5 + (2 Ч 0.5))
Connection cable
U
V
W
Connection cable
(4 Ч 1.0 + (2 Ч 0.5))
EYP0003AxxxxM01A00 E94AS
E94AM
EVS93
ECS
E84AVT
EYP0010AxxxxM01A00
EYP0003AxxxxM04A00
EYP0010AxxxxM04A00
(4 Ч 1.5 + (2 Ч 0.5))
EYP0004AxxxxM01A00 E94AS
E94AM
EVS93
ECS
E84AVT
EYP0011AxxxxM01A00
EYP0004AxxxxM04A00
EYP0011AxxxxM04A00
(4 Ч 2.5 + (2 Ч 0.5))
EYP0005AxxxxM01A00 E94AS
E94AM
EVS93
ECS
E84AVT
EYP0012AxxxxM01A00
EYP0005AxxxxM04A00
EYP0012AxxxxM04A00
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
