Servo motors: Motor cable selection
MCA motor
MCA22P08−...5F
l
153
EDSYPFLD EN 8.0
Connection cable
U
V
W
Connection cable
(4 Ч 2.5 + (2 Ч 0.5))
–
E94AS
E94AM
EVS93
ECS
E84AVT
EYP0012YxxxxA00A00
(4 Ч 4.0 + (2 Ч 1.0))
EYP0006YxxxxA00A00
E94AS
E94AM
EVS93
ECS
E84AVT
EYP0013YxxxxA00A00
(4 Ч 6.0 + (2 Ч 1.0))
EYP0007YxxxxA00A00
E94AS
E94AM
EVS93
ECS
E84AVT
EYP0014YxxxxA00A00
(4 Ч 10.0 + (2 Ч 1.0))
EYP0008YxxxxA00A00
E94AS
E94AM
EVS93
ECS
E84AVT
EYP0015YxxxxA00A00
(4 Ч 16.0 + (2 Ч 1.0))
EYP0009YxxxxA00A00
E94AS
E94AM
EVS93
ECS
E84AVT
EYP0016YxxxxA00A00
Die EYP0006... system cable can only be connected to the motor using a reducer.
Die EYP0007... system cable can only be connected to the motor using a reducer.
The EYP0012... system cable can only be connected to the motor using a reducer.
Die EYP0013... system cable can only be connected to the motor using a reducer.
Die EYP0014... system cable can only be connected to the motor using a reducer.
Cable properties
Mechanical/design:
^ 53
Electrical/temperature range:
^ 54
Chemical:
^ 55
Important notes
For trailing cables:
^ 27
For the dimensioning:
