Three−phase asynchronous motors MFxxx: Motor cable selection
MFxMAxx132−12, MFxMAxx132−22, MFxMAxx132−32
Star connection − terminal box, 10−core system cable
8
l
794 EDSYPFLD EN 8.0
8.7.2 Star connection − terminal box, 10−core system cable
U
V
W
[mm 2 ] E94Ax EVF93 E82xV E84AV
E84DS
E84DH
MFxxxxx132−12
MFxxxxx132−22
MFxxxxx132−32
(4 Ч 10.0 + (2 Ч 1.0) + (4 Ч 1.0)) U, V, W, PE, ,
J ˘
Connection cable
U
V
W
Connection cable
(4 Ч 10.0 + (2 Ч 1.0) + (4 Ч 1.0))
EYP0047AxxxxA00A00
E94Ax
EVF93
E82xV
E84AV
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
