4.3 Feedback cables
For your convenience, choose your customised feedback cable using a maximum of three
tables. The structure of the tables always provides for the same order in which the
components appear (’feedback − feedback cable − controller’).
4.3.1 How to find your feedback cable
1. Use the bookmarklets of the PDF document to select your feedback system in the
chapter "Selection of feedback cables".
2. Navigate to the corresponding chapter.
3. Select the "Feedbacks with plug connection" section or the "Feedbacks with
terminal box" section, according to the connection type.
– Structure of the "Feedback type" selection table: (
¶ 70)
4. Select a connection cable or a combination of connection cable and extension cable.
– Structure of the "Connection cable" selection table: (
¶ 71)
– Structure of the "Extension cable" selection table: (
¶ 72)
5. Determine the product key of the connection cable or the extension cable,
respectively.
– The product key gives information about the cross−section, the laying system, and
the design of the cable ends.
– The product key also is the order designation.
