Servo motors: Motor cable selection
MCS motor
MCS12D17, MCS12D20, MCS12D35
5
l
219 EDSYPFLD EN 8.0
Motors with terminal boxes
U
V
W
[mm 2 ]
EVS93
E84AVT
E94AS
E94AM
ECS
MCS12D17−...Fxx
MCS12D20−...S00
MCS12D20L...S00
MCS12D35−...Fxx (4 Ч 1.0 + (2 Ч 0.5))
U, V, W, PE X105, X107 X24, X25 (4 Ч 1.5 + (2 Ч 0.5))
(4 Ч 2.5 + (2 Ч 0.5))
Connection cable
U
V
W
Connection cable
(4 Ч 1.0 + (2 Ч 0.5))
EYP0003YxxxxA00A00
E94AS
E94AM
EVS93
ECS
E84AVT
EYP0010YxxxxA00A00
(4 Ч 1.5 + (2 Ч 0.5))
EYP0004YxxxxA00A00
E94AS
E94AM
EVS93
ECS
E84AVT
EYP0011YxxxxA00A00
(4 Ч 2.5 + (2 Ч 0.5))
EYP0005YxxxxA00A00
E94AS
E94AM
EVS93
ECS
E84AVT
EYP0012YxxxxA00A00
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
