Three−phase asynchronous motors MDxMA: Motor cable selection
MDxMAxx132−22
Star connection − plug, 10−core system cable
6
l
592 EDSYPFLD EN 8.0
6.11.3 Star connection − plug, 10−core system cable
U
V
W
[mm 2 ] E94Ax EVF93 E82xV E84AV
E84DS
E84DH
MDxMAxx132−22, * (4 Ч 2.5 + (2 Ч 0.5) + (4 Ч 0.5)) U, V, W, PE, ,
J X21
Connection cable
U
V
W
Connection cable
(4 Ч 2.5 + (2 Ч 0.5) + (4 Ч 0.5))
EYP0040AxxxxH09A00
E94Ax
EVF93
E82xV
E84AV
EYP0040AxxxxH09Q09
E84DSxB
E84DHxB
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
Extension cable
U
V
W
Connection cable Connector Connection cable
EYP0040AxxxxH09Q09 EWZ0065 EYP0040AxxxxH09A00
E94Ax
EVF93
E82xV
E84AV
EYP0040AxxxxH09Q09
EWZ0065
EYP0040AxxxxH09Q09
E84DSxB
E84DHxB
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
