Lenze EY System cables and system connectors - Manual (Page 116)

Servo motors: Motor cable selection
MCA motor
MCA19S23
5
l
116 EDSYPFLD EN 8.0
Extension cable
U
V
W
Extension cable Connection cable
(4 Ч 1.0 + (2 Ч 0.5))
EYP0003VxxxxA00P04
EYP0003AxxxxM01A00 E94AS
E94AM
EVS93
ECS
E84AVT
EYP0010AxxxxM01A00
EYP0010VxxxxA00P04
EYP0003AxxxxM04A00
EYP0010AxxxxM04A00
(4 Ч 1.5 + (2 Ч 0.5))
EYP0004VxxxxA00P04
EYP0004AxxxxM01A00 E94AS
E94AM
EVS93
ECS
E84AVT
EYP0011AxxxxM01A00
EYP0011VxxxxA00P04
EYP0004AxxxxM04A00
EYP0011AxxxxM04A00
(4 Ч 2.5 + (2 Ч 0.5))
EYP0005VxxxxA00P04
EYP0005AxxxxM01A00 E94AS
E94AM
EVS93
ECS
E84AVT
EYP0012AxxxxM01A00
EYP0012VxxxxA00P04
EYP0005AxxxxM04A00
EYP0012AxxxxM04A00
(4 Ч 4.0 + (2 Ч 1.0))
EYP0006VxxxxA00P05
EYP0006AxxxxM02A00 E94AS
E94AM
EVS93
ECS
E84AVT
EYP0013AxxxxM02A00
EYP0013VxxxxA00P05
EYP0006AxxxxM05A00
EYP0013AxxxxM05A00
Die EYP0003... system cable can only be connected to the motor using a reducer.
Die EYP0004... system cable can only be connected to the motor using a reducer.
Die EYP0010... system cable can only be connected to the motor using a reducer.
Die EYP0011... system cable can only be connected to the motor using a reducer.
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
