Three−phase asynchronous motors 13.7x0: Motor cable selection
13.710.xx, 13.750.xx
Star or delta connection − terminal box, 6−core system cable
l
796
EDSYPFLD EN 8.0
Extension cable
U
V
W
Extension cable
Connection cable
(4 Ч 1.0 + (2 Ч 0.5))
E94Ax
EVF93
E82xV
E84AV
EYP0003VxxxxA00P04
EYP0003AxxxxM01A00
EYP0010AxxxxM01A00
EYP0010VxxxxA00P04
EYP0003AxxxxM04A00
EYP0010AxxxxM04A00
(4 Ч 1.5 + (2 Ч 0.5))
E94Ax
EVF93
E82xV
E84AV
EYP0004VxxxxA00P04
EYP0004AxxxxM01A00
EYP0011AxxxxM01A00
EYP0011VxxxxA00P04
EYP0004AxxxxM04A00
EYP0011AxxxxM04A00
(4 Ч 2.5 + (2 Ч 0.5))
E94Ax
EVF93
E82xV
E84AV
EYP0005VxxxxA00P04
EYP0005AxxxxM01A00
EYP0012AxxxxM01A00
EYP0012VxxxxA00P04
EYP0005AxxxxM04A00
EYP0012AxxxxM04A00
The EYP0004... system cable can only be connected to the motor using an extension.
The EYP0005... system cable can only be connected to the motor using an enlarger.
The EYP0010... system cable can only be connected to the motor using an extension.
The EYP0011... system cable can only be connected to the motor using an extension.
The EYP0012... system cable can only be connected to the motor using an enlarger.
Cable properties
Mechanical/design:
^ 53
Electrical/temperature range:
^ 54
Chemical:
^ 55
Important notes
For trailing cables:
^ 27
For the dimensioning:
