Servo motors: Motor cable selection
MCA motor
MCA17N35
5
l
103 EDSYPFLD EN 8.0
Motors with terminal boxes
U
V
W
[mm 2 ]
EVS93
E84AVT
E94AS
E94AM
ECS
MCA17N35−...Fxx
(4 Ч 1.5 + (2 Ч 0.5))
U, V, W, PE X105, X107 X24, X25
(4 Ч 2.5 + (2 Ч 0.5))
Connection cable
U
V
W
Connection cable
(4 Ч 1.5 + (2 Ч 0.5))
–
E94AS
E94AM
EVS93
ECS
E84AVT
EYP0011YxxxxA00A00
(4 Ч 2.5 + (2 Ч 0.5))
EYP0005YxxxxA00A00
E94AS
E94AM
EVS93
ECS
E84AVT
EYP0012YxxxxA00A00
The EYP0012... system cable can only be connected to the motor using an enlarger.
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
