Three−phase asynchronous motors MDxMA: Motor cable selection
MDxMAxx112−22
Delta connection − terminal box, 8−core system cable
6
l
537 EDSYPFLD EN 8.0
6.6.11 Delta connection − terminal box, 8−core system cable
U
V
W
[mm 2 ] E94Ax EVF93 E82xV E84AV E84DVB
E84DS
E84DH
MDxMAxx112−22, - (4 Ч 2.5 + 2(2 Ч 0.5)) U, V, W, PE, , J
X1,
X21
X21
Connection cable
U
V
W
Connection cable
(4 Ч 2.5 + 2(2 Ч 0.5))
EYP0038AxxxxA00A00
E94Ax
EVF93
E82xV
E84AV
E84DVB (X1)
EYP0038AxxxxA00Q11
E84DVB (X21)
E84DSxC
E84DHxC
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
Extension cable
U
V
W
Extension cable Connection cable
(4 Ч 2.5 + 2(2 Ч 0.5)) E94Ax
EVF93
E82xV
E84AV
E84DVB (X1)
EYP0038VxxxxA00P07
EYP0038AxxxxM07A00
EYP0038AxxxxM08A00
EYP0038VxxxxA00P07
EYP0038AxxxxM07Q11 E84DVB (X21)
E84DSxC
E84DHxC EYP0038AxxxxM08Q11
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
