Technical data
Cable end characteristic
Cable end on the controller side
l
57
EDSYPFLD EN 8.0
3.2.2
Cable end on the controller side
This characteristic describes the end of the system cable on the controller side. The plug−in
connectors are designed as pins.
Charac−
teristic
No. of
poles
Rated voltage
Core
cross−section
Type
Power
P04
6
AC/DC 630 V
1.0 ... 2.5 mm
2
Plug−in connector with SpeedTec
P05
8
AC/DC 630 V
2.5 ... 4.0 mm
2
Plug−in connector with SpeedTec
P06
8
AC/DC 630 V
6.0 ... 16.0 mm
2
Plug−in connector with SpeedTec
P07
8
AC/DC 630 V
1.0 ... 2.5 mm
2
Plug−in connector with SpeedTec
Q08
10
AC 500 V
1.5 mm
2
Modular plug−in connector 40A
Q09
10
AC 500 V
2.5 mm
2
Modular plug−in connector 40A
Q10
8
AC 500 V
1.5 mm
2
Plug−in connector Q8
Q11
8
AC 500 V
2.5 mm
2
Plug−in connector Q8
Blower
J03
8
AC/DC 630 V
1.0 ... 2.5 mm
2
Plug−in connector with SpeedTec
J04
7
AC/DC 630 V
1.0 ... 1.5 mm
2
Plug−in connector with SpeedTec
J05
7
AC/DC 630 V
1.0 ... 1.5 mm
2
Plug−in connector with SpeedTec
Feedback
G06
12
AC/DC 125 V
0.14 ... 1.0 mm
2
Plug−in connector with SpeedTec
G07
12
AC/DC 125 V
0.14 ... 1.0 mm
2
Plug−in connector with SpeedTec,
coding: 20°
G08
17
AC/DC 125 V
0.14 ... 0.5 mm
2
Plug−in connector with SpeedTec
G09
17
AC/DC 125 V
0.14 ... 0.5 mm
2
Plug−in connector with SpeedTec,
coding: 20°
S01
9
AC/DC 50 V
0.14 mm
2
Sub−D plug
S02
9
AC/DC 50 V
0.14 mm
2
Sub−D plug with locking hook
S03
15
AC/DC 50 V
0.14 ... 0.5 mm
2
Sub−D plug with locking hook
S04
9
AC/DC 50 V
0.14 mm
2
Sub−D plug, large cable entry
S05
9
AC/DC 50 V
0.14 mm
2
Sub−D plug with locking hook, large cable entry
S06
15
AC/DC 50 V
0.14 ... 0.5 mm
2
Sub−D plug
W02
9
AC/DC 50 V
0.14 mm
2
Sub−D plug, (socket)
W04
9
AC/DC 50 V
0.14 mm
2
Sub−D plug, large cable entry(socket)
B02
5
AC/DC 50 V
0.34 mm
2
M12−A connector
Cable end without plug−in connector
A00
–
–
–
–
)
Note!
When Sub−D plug W04 is used, an additional free space of 50 mm must be
considered due to the depth of the plug.
If the required free space is not available, a connection cable for fixed
installation and plug W02 can be used in combination with an extension cable
suitable for trailing to solve the application.
