Feedback cable selection
Resolver cables
11

807 EDSYPFLD EN 8.0
11 Feedback cable selection
11.1 Resolver cables
Feedbacks with plug connections
[mm 2 ] E94Ax… EVS93… ECS… 931E… E84AVT…
RS0
RS1
3 (2 Ч 0.14) + (3 Ч 0.14) X7 X7 X7 X7 X7
Connection cable
Connection cable
EYF0017AxxxxF01S01
EVS93…,
ECS…,
931E…
EYF0020AxxxxF01S04
EYF0017AxxxxF05S01
EYF0020AxxxxF05S04
EYF0017AxxxxF01S02
E94AS…
E94AM…
E84AVT…
EYF0020AxxxxF01S05
EYF0017AxxxxF05S02
EYF0020AxxxxF05S05
Cable properties
Mechanical/design:  53 Electrical/temperature range:  54 Chemical:  55
Important notes
For trailing cables:  27
