Product description

Overview of possible configurations
Blower cables

2

l

40

EDSYPFLD EN 8.0

2.3.4

Blower cables

Connection cable with connector, see (

41)

EYL xxxx A xxxx L0x A00

U

V

W

hb_luefter_02

Connection cable without connector, see (

42)

EYL xxxx Y xxxx A00 A00

U

V

W

hb_luefter_03

Extension cable, see (

43)

EYL xxxx V xxxx L0x J0x

EYL xxxx A xxxx L0x A00

EYL xxxx V xxxx A00 J0x

U

U

V

V

W

W

hb_luefter_04
