Lenze EY System cables and system connectors - Manual (Page 274)

Servo motors: Motor cable selection
MCS motor
MCS14H28
5
l
274 EDSYPFLD EN 8.0
Connection cable
U
V
W
Connection cable
(4 Ч 2.5 + (2 Ч 0.5))
EYP0005AxxxxM02A00 E94AS
E94AM
EVS93
ECS
E84AVT
EYP0012AxxxxM02A00
EYP0005AxxxxM05A00
EYP0012AxxxxM05A00
(4 Ч 4.0 + (2 Ч 1.0))
EYP0006AxxxxM02A00 E94AS
E94AM
EVS93
ECS
E84AVT
EYP0013AxxxxM02A00
EYP0006AxxxxM05A00
EYP0013AxxxxM05A00
(4 Ч 6.0 + (2 Ч 1.0))
EYP0007AxxxxM03A00 E94AS
E94AM
EVS93
ECS
E84AVT
EYP0014AxxxxM03A00
EYP0007AxxxxM06A00
EYP0014AxxxxM06A00
(4 Ч 10.0 + (2 Ч 1.0))
EYP0008AxxxxM03A00 E94AS
E94AM
EVS93
ECS
E84AVT
EYP0015AxxxxM03A00
EYP0008AxxxxM06A00
EYP0015AxxxxM06A00
(4 Ч 16.0 + (2 Ч 1.0))
EYP0009AxxxxM03A00 E94AS
E94AM
EVS93
ECS
E84AVT
EYP0016AxxxxM03A00
EYP0009AxxxxM06A00
EYP0016AxxxxM06A00
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
