Feedback cable selection
Encoder cables
IG512−24V−H, IGxxxx−24V−H (HTL with four−core system cable)
11
l
820 EDSYPFLD EN 8.0
Feedbacks with terminal boxes
[mm 2 ] E84AVH E84AVT
E84DS
E84DH
E82xV
IG512−24V−H
IG1024−24V−H
IG2048−24V−H
(2 Ч 2 Ч 0.34) X5 X5 X41 X3 1)
1) Connection via the E82ZAFSC module or the E82ZAFAC module is possible.
Connection cable
Connection cable
EYF0048AxxxxA00B02
E84DS
E84DH
EYF0048YxxxxA00A00
E82xV
E84AVH
E84AVT
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27
Extension cable
Extension cable Connection cable
EYF0048VxxxxA00G07
EYF0048AxxxxF02B02
E84DS
E84DH
EYF0048AxxxxF06B02
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27
