Lenze EY System cables and system connectors - Manual (Page 553)

Three−phase asynchronous motors MDxMA: Motor cable selection
MDxMAxx112−32
Star connection − plug, 8−core system cable
6
l
553 EDSYPFLD EN 8.0
6.8.2 Star connection − plug, 8−core system cable
U
V
W
[mm 2 ] E94Ax EVF93 E82xV E84AV E84DVB
E84DS
E84DH
MDxMAxx112−32, *
(4 Ч 1.5 + 2(2 Ч 0.5))
U, V, W, PE, ,
J
X1,
X21
X21
(4 Ч 2.5 + 2(2 Ч 0.5))
Connection cable
U
V
W
Connection cable
(4 Ч 1.5 + 2(2 Ч 0.5))
EYP0037AxxxxM07A00 E94Ax
EVF93
E82xV
E84AV
E84DVB (X1)
EYP0037AxxxxM08A00
EYP0037AxxxxH10A00
EYP0037AxxxxM07Q10
E84DVB (X21)
E84DSxC
E84DHxC
EYP0037AxxxxM08Q10
EYP0037AxxxxH10Q10
(4 Ч 2.5 + 2(2 Ч 0.5))
EYP0038AxxxxM07A00 E94Ax
EVF93
E82xV
E84AV
E84DVB (X1)
EYP0038AxxxxM08A00
EYP0038AxxxxH11A00
EYP0038AxxxxM07Q11
E84DVB (X21)
E84DSxC
E84DHxC
EYP0038AxxxxM08Q11
EYP0038AxxxxH11Q11
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
