Servo motors: Motor cable selection
MCA motor
MCA20X29
5
l
130 EDSYPFLD EN 8.0
5.1.14 MCA20X29
Motors with plug connections
U
V
W
[mm 2 ]
EVS93
E84AVT
E94AS
E94AM
ECS
MCA20X29− 2Fxx
(4 Ч 10.0 + (2 Ч 1.0))
U, V, W, PE X105, X107 X24, X25
(4 Ч 16.0 + (2 Ч 1.0))
Connection cable
U
V
W
Connection cable
(4 Ч 10.0 + (2 Ч 1.0))
– E94AS
E94AM
EVS93
ECS
E84AVT
EYP0015AxxxxM03A00
–
EYP0015AxxxxM06A00
(4 Ч 16.0 + (2 Ч 1.0))
EYP0009AxxxxM03A00 E94AS
E94AM
EVS93
ECS
E84AVT
EYP0016AxxxxM03A00
EYP0009AxxxxM06A00
EYP0016AxxxxM06A00
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
