Page 56: Technical data
Technical data
Cable end characteristic
Cable end on the motor side
l
56
EDSYPFLD EN 8.0
3.2
Cable end characteristic
3.2.1
Cable end on the motor side
This characteristic describes the end of the system cable on the motor side. The plug−in
connectors are designed as sockets.
Charac−
teristic
No. of
poles
Rated voltage
Core
cross−section
Type
Power
M01
6
AC/DC 630 V
1.0 ... 2.5 mm
2
Plug−in connector with screw plug
M02
8
AC/DC 630 V
2.5 ... 4.0 mm
2
Plug−in connector with screw plug
M03
8
AC/DC 630 V
6.0 ... 16.0 mm
2
Plug−in connector with screw plug
M04
6
AC/DC 630 V
1.0 ... 2.5 mm
2
Plug−in connector with SpeedTec
M05
8
AC/DC 630 V
2.5 ... 4.0 mm
2
Plug−in connector with SpeedTec
M06
8
AC/DC 630 V
6.0 ... 16.0 mm
2
Plug−in connector with SpeedTec
M07
8
AC/DC 630 V
1.0 ... 2.5 mm
2
Plug−in connector with screw plug
M08
8
AC/DC 630 V
1.0 ... 2.5 mm
2
Plug−in connector with SpeedTec
H07
10
AC 500 V
1.5 mm
2
Modular plug−in connector 16A
H08
10
AC 500 V
2.5 mm
2
Modular plug−in connector 16A
H09
10
AC 500 V
2.5 mm
2
Modular plug−in connector 40A
H10
8
AC 500 V
1.5 mm
2
Plug−in connector 10E−
*
H11
8
AC 500 V
2.5 mm
2
Plug−in connector 10E−
*
H12
8
AC 500 V
1.5 mm
2
Plug−in connector 10E−
-
H13
8
AC 500 V
2.5 mm
2
Plug−in connector 10E−
-
H14
10
AC 500 V
4.0 mm
2
Modular plug−in connector 40A
H15
10
AC 500 V
10.0 mm
2
Modular plug−in connector 40A
Blower
L01
8
AC/DC 630 V
1.0 ... 2.5 mm
2
Plug−in connector with screw plug
L02
7
AC/DC 630 V
1.0 ... 1.5 mm
2
Plug−in connector with screw plug
L03
8
AC/DC 630 V
1.0 ... 2.5 mm
2
Plug−in connector with SpeedTec
L04
7
AC/DC 630 V
1.0 ... 1.5 mm
2
Plug−in connector with SpeedTec
L05
7
AC/DC 630 V
1.0 ... 1.5 mm
2
Plug−in connector with screw plug
L06
7
AC/DC 630 V
1.0 ... 1.5 mm
2
Plug−in connector with SpeedTec
Feedback
F01
12
AC/DC 125 V
0.14 ... 1.0 mm
2
Plug−in connector with screw plug
F02
12
AC/DC 125 V
0.14 ... 1.0 mm
2
Plug−in connector with screw plug,
coding: 20°
F03
17
AC/DC 125 V
0.14 ... 0.5 mm
2
Plug−in connector with screw plug
F04
17
AC/DC 125 V
0.14 ... 0.5 mm
2
Plug−in connector with screw plug,
coding: 20°
F05
12
AC/DC 125 V
0.14 ... 1.0 mm
2
Plug−in connector with SpeedTec
F06
12
AC/DC 125 V
0.14 ... 1.0 mm
2
Plug−in connector with SpeedTec,
coding: 20°
F07
17
AC/DC 125 V
0.14 ... 0.5 mm
2
Plug−in connector with SpeedTec
F08
17
AC/DC 125 V
0.14 ... 0.5 mm
2
Plug−in connector with SpeedTec,
coding: 20°
D01
4
AC/DC 50 V
0.34 mm
2
M12−A connector
Cable end without plug−in connector
A00
–
–
–
–
