Blower cable selection
MCS motor
1-phase fan with plug connection
10

797 EDSYPFLD EN 8.0
10 Blower cable selection
10.1 MCS motor
10.1.1 1-phase fan with plug connection
U
V
W
[mm 2 ]
MCS...Fxx 5 × 1.0
Connection cable
U
V
W Connection cable
5 × 1.0
EYL0001AxxxxL02A00
EYL0002AxxxxL02A00
EYL0001AxxxxL04A00
EYL0002AxxxxL04A00
Extension cable
U
V
W
Extension cable Connection cable
5 × 1.0
EYL0001VxxxxL02J04 EYL0001AxxxxL02A00
EYL0001VxxxxL04J04 EYL0002AxxxxL02A00
EYL0002VxxxxL02J04 EYL0001AxxxxL04A00
EYL0002VxxxxL04J04 EYL0002AxxxxL04A00
Cable properties
Mechanical/design:  53 Electrical/temperature range:  54 Chemical:  55
Important notes
For trailing cables:  27
