Feedback cable selection
Encoder cables
IG512−24V−H, IGxxxx−24V−H (HTL with 10−core system cable)
11
l
818 EDSYPFLD EN 8.0
Extension cable
Extension cable Connection cable
EYF0018VxxxxA00G07
EYF0018AxxxxF02W02
EVF93
EYF0019AxxxxF02W04
EYF0019VxxxxA00G07
EYF0018AxxxxF06W02
EYF0019AxxxxF06W04
EYF0018VxxxxA00G07
EYF0018AxxxxF02A00
E82xV
E84AVH
E84AVT
EYF0019AxxxxF02A00
EYF0019VxxxxA00G07
EYF0018AxxxxF06A00
EYF0019AxxxxF06A00
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27
