Three−phase asynchronous motors MDxMA: Motor cable selection
MDxMAxx063−xx, MDxMAxx071−xx, MDxMAxx080−xx, MDxMAxx090−xx
Star or delta connection − plug, 10−core system cable
6
l
430 EDSYPFLD EN 8.0
6.1.3 Star or delta connection − plug, 10−core system cable
U
V
W
[mm 2 ] E94Ax EVF93 E82xV E84AV
E84DS
E84DH
MDxMAxx063−xx
MDxMAxx071−xx
MDxMAxx080−xx
MDxMAxx090−xx
(4 Ч 1.5 + (2 Ч 0.5) + (4 Ч 0.5))
U, V, W, PE, ,
J X21
(4 Ч 2.5 + (2 Ч 0.5) + (4 Ч 0.5))
Connection cable
U
V
W
Connection cable
(4 Ч 1.5 + (2 Ч 0.5) + (4 Ч 0.5))
EYP0039AxxxxH07A00
E94Ax
EVF93
E82xV
E84AV
EYP0039AxxxxH07Q08
E84DSxB
E84DHxB
(4 Ч 2.5 + (2 Ч 0.5) + (4 Ч 0.5))
EYP0040AxxxxH08A00
E94Ax
EVF93
E82xV
E84AV
EYP0040AxxxxH08Q09
E84DSxB
E84DHxB
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
