Three−phase asynchronous motors MHxMA: Motor cable selection
MHxMAxx100−32
Delta connection − terminal box, 10−core system cable
7
l
642 EDSYPFLD EN 8.0
Extension cable
U
V
W
Connection cable Connector Connection cable
(4 Ч 1.5 + (2 Ч 0.5) + (4 Ч 0.5))
EYP0039AxxxxA00Q08 EWZ0064 EYP0039AxxxxH07A00
E94Ax
EVF93
E82xV
E84AV
EYP0039AxxxxA00Q08 EWZ0064 EYP0039AxxxxH07Q08
E84DSxB
E84DHxB
(4 Ч 2.5 + (2 Ч 0.5) + (4 Ч 0.5))
EYP0040AxxxxA00Q09 EWZ0064 EYP0040AxxxxH08A00
E94Ax
EVF93
E82xV
E84AV
EYP0040AxxxxA00Q09 EWZ0064 EYP0040AxxxxH08Q09
E84DSxB
E84DHxB
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
