Lenze EY System cables and system connectors - Manual (Page 799)

Blower cable selection
MCA motor
1−phase fan with terminal box
10
l
799 EDSYPFLD EN 8.0
10.2.2 1−phase fan with terminal box
U
V
W
[mm 2 ]
MCA...Fxx 5 × 1.0
Connection cable
U
V
W
Connection cable
5 × 1.0
EYL0001YxxxxA00A00
EYL0002YxxxxA00A00
Extension cable
U
V
W
Extension cable Connection cable
5 × 1.0
EYL0001VxxxxA00J04
EYL0001AxxxxL02A00
EYL0002AxxxxL02A00
EYL0002VxxxxA00J04
EYL0001AxxxxL04A00
EYL0002AxxxxL04A00
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27
