Servo motors: Motor cable selection
MCA motor
MCA19S17
5
l
109 EDSYPFLD EN 8.0
5.1.9 MCA19S17
Motors with plug connections
U
V
W
[mm 2 ]
EVS93
E84AVT
E94AS
E94AM
ECS
MCA19S17−...Fxx
(4 Ч 2.5 + (2 Ч 0.5))
U, V, W, PE X105, X107 X24, X25
(4 Ч 4.0 + (2 Ч 1.0))
Connection cable
U
V
W
Connection cable
(4 Ч 2.5 + (2 Ч 0.5))
EYP0005AxxxxM02A00 E94AS
E94AM
EVS93
ECS
E84AVT
EYP0012AxxxxM02A00
EYP0005AxxxxM05A00
EYP0012AxxxxM05A00
(4 Ч 4.0 + (2 Ч 1.0))
EYP0006AxxxxM02A00 E94AS
E94AM
EVS93
ECS
E84AVT
EYP0013AxxxxM02A00
EYP0006AxxxxM05A00
EYP0013AxxxxM05A00
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27 For the dimensioning: ^ 24 et seqq.
