Digital frequency cable selection
EMF2132IB digital frequency distributor
12
l
838 EDSYPFLD EN 8.0
12.6 EMF2132IB digital frequency distributor
Master [mm 2 ] E94Ax E84AVT ECS EVx93 EZAEVA00x 1) EMF2132IB 1)
EMF2132IB, X2, X3, X4 3 (2 Ч 0.14) + (3 Ч 0.14) X9 2) X8 X8 X9 X1 X1
1) Digital frequency distributor
2) E94AYFLF digital frequency module
Connection cable
Connection cable
EYD0017AxxxxW03S01 E94Ax
EYD0017AxxxxS08S01 E84AVT
EYD0017AxxxxW01S01
ECS
EVx93
EMF2132IB
EYD0017AxxxxS08S01 EZAEVA00x
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
