Digital frequency cable selection
Inverter Drives 8400
12
l
834 EDSYPFLD EN 8.0
12.2 Inverter Drives 8400
Master [mm 2 ] E94Ax E84AVT ECS EVx93 EZAEVA00x 1) EMF2132IB 1)
E84AVT , X8
3 (2 Ч 0.14) + (3 Ч 0.14) X9 2) ˘ X8 X9 ˘ X1
3 (2 Ч 0.14) + (4 Ч 0.14)
+ 2 (2 Ч 0.5)
˘ X8 ˘ ˘ X1 ˘
1) Digital frequency distributor
2) E94AYFLF digital frequency module
Connection cable
Connection cable
EYD0017AxxxxW03S07 E94Ax
EYD0021AxxxxS10S09 E84AVT
EYD0017AxxxxW01S07
ECS
EVx93
EMF2132IB
EYD0021AxxxxS10S09 EZAEVA00x
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
