Feedback cable selection
Encoder cables
IG512−24V−H, IGxxxx−24V−H (HTL with four−core system cable)
11
l
819 EDSYPFLD EN 8.0
11.2.3 IG512−24V−H, IGxxxx−24V−H (HTL with four−core system cable)
)
Note!
The four−core system cables cannot be configured and are only available in
fixed lengths up to 20 m.
Feedbacks with plug connections
[mm 2 ] E84AVH E84AVT
E84DS
E84DH
E82xV
IG512−24V−H
IG1024−24V−H
IG2048−24V−H
(2 Ч 2 Ч 0.34) ˘ ˘ X41 ˘
Connection cable
Connection cable
IG512−24V−H
IG1024−24V−H
IG2048−24V−H
EYF0048AxxxxF02B02
E84DS ,
E84DH
EYF0048AxxxxF06B02
Cable properties
Mechanical/design: ^ 53 Electrical/temperature range: ^ 54 Chemical: ^ 55
Important notes
For trailing cables: ^ 27
