XTC/C - XTC/2 Operating Manual
3.7.2 Inputs
Inputs are activated by pulling the specific input's terminal to ground (<0.8V)
through a contact closure to common (GND) or with TTL/CMOS logic having
current sink capability of 2 ma (1 low power TTL load). These ports are read
every 250 ms; signals must be present during a read cycle.
Table 3-6 System I/O Connector
Input #
Pin #
Function
Description
13,14,15,
16,17
Input Common
(GND)
Used as reference for activating any of
the inputs
1
18
START deposition
Detection of a falling edge duplicates
front panel START
2
19
STOP deposition
Detection of a falling edge induces a
STOP
3
20
END deposit
Detection of a falling edge terminates
the Deposit state just as if the FINAL
THK were achieved.
Configuration switch #12 set for "Standard" Input Option:
4
21
SAMPLE INITIATE
Detection of a falling edge initiates a
RateWatcher sample if the film is
programmed for this feature.
5
22
SAMPLE INHIBIT
Application of a ground reference
voltage maintains the RateWatcher in
the Hold condition.
6
23
CRYSTAL FAIL
INHIBIT
Application of a ground reference
voltage prohibits the closure of the
Crystal Fail Relay and the associated
Stop.
7
24
ZERO thickness
Detection of a falling edge duplicates
the front panel ZERO.
8
25
SOAK 2 HOLD
Application of a ground reference
voltage extends the SOAK 2 state until
the signal/closure is removed.
