4 - 7

IP

N 07

4-

18

3X

XTC/C - XTC/2 Operating Manual

10.RATE RAMP
TIME

Rate control, desired rate
changing. [Thick Spt, New Rate,
R.Ramp Time]

Closed

Closed

Open

11.RATEWATCHER
(SAMPLE)

Rate control. [Sample %]

Closed

Closed

Open

12.RATEWATCHER
(HOLD)

Constant power, based on last
sample’s average power. [Hold
Time]

Closed

Open

Open

13.MANUAL

Source power controlled by hand
held controller.

Closed

Closed

Open

14.TIME-POWER

Crystal failed; source maintained at
average control power prior to
crystal failure. [Time Pwr Y]

Closed

Closed

Open

NOTE: 15 through 16 are Post-Deposit states.

15.IDLE RAMP

Source changing to Idle Power.
[Idle Ramp]

Open

Open

Open

16a. IDLE POWER
(=0%)

Source maintained at zero power;
will accept a START command.
[Idle Pwr]

Open

Open

Open

16b. IDLE POWER
(>0%)

Source resting at Idle Power; will
accept a START command.

Open

Open

Open

NOTE: The STOP state—instrument will accept a START provided a Crystal Fail has
not occurred. See also

section 4.16 on page 4-26

.

Table 4-1 State Descriptions (continued)

STATE

CONDITION

RELAY CONTACT STATUS

Source

Shutter

Sensor

Shutter
