4.6.1 Q-Factor (Quality)

The Q-Factor is a measure of the quality of the rate control of the active
process. When the Q-Factor is activated the instrument senses the amount of
rate deviation from the desired programmed rate. Setting Q between 1 and 9
activates an algorithm which sets threshold limits on allowed rate deviation. If
the rate deviation relative to the programmed rate is greater than the
programmed threshold limit, the Q counter is incremented. If the rate deviation
is less than the programmed threshold, the Q counter is decremented. Q is not
allowed to have negative values. If the Q counter exceeds a value of 50, the
instrument will then automatically crystal switch, complete the process on
TIME-POWER or STOP the process. The quality limits (or band of allowed rate
deviation) are shown in

Table 4-3

. This deviation is computed on each

individual reading of the crystal during the deposit phase, i.e., every 250 ms.

.

Example

If the Programmed rate is: 45 Å/s and the actual rate is: 40 Å/s, then:

[2]

Table 4-3 Quality Limits

Q-Factor

Threshold of Rate

Deviation (%)

0

Disabled

1

30.0

2

25.0

3

20.0

4

15.0

5

12.5

6

10.0

7

7.5

8

5.0

9

2.5

Deviation (%)

45

40

45

-------------------

100%

Ч

11.1%

=

=
