Cygnus Operating Manual
5
(0x05)
General Errors 2 Bytes
0x8000 Power Loss
0x4000 No Disk in Drive
0x2000 Disk is Full
0x1000 Disk Write Protected
0x0800 Disk Error
0x0400 File Checksum Error
0x0200 File Format Error
0x0100 File Read Error
0x0080 File Range Error
0x0040 Parameters Defaulted
0x0020 Data Log Failure
0x0008 Memory Allocation Fail
0x0004 Loaded Different Version
6
(0x06)
Get Date 3 Integers, Month, Day, and Year.
7
(0x07)
Get Time 3 Integers, Hour, Minute, Second
8
(0x08)
Channels with
Errors and
Status 2 Bytes. The first is Channel Error with the
MSB representing Channel 1. The second is
Status with the MSB representing Channel 1.
9
(0x09)
Thickness Sum
x, x = 0 to 3;
0 = All
equations, 1 to 3
refer to specific
thickness
equation per
general
parameters
0 to 3 3 Floats for Action Value = 0
1 Float for Action Value = 1 to 3
representing Thickness in kiloAngstroms.
10
(0x0A)
General Status
Messages 2 bytes
0x8000 Test = Test Mode On
0x4000 Remote Lock
0x2000 Program Lock
Table 5-9 Status General Commands (continued)
SG
Command
ID Meaning
Action
Value Response
